STANDARD FEATURES
EPA 2020 Certified
Reliable, Durable, Catalytic-free Technology
Extended Burn Technology (EBT)
Airwash Technology for clear, clean glass
Floating firebox for extended stove life
High-tech multi-port combustion air injection system
304 Stainless Steel Baffle, insulation cover, rails and flame shield
Rich Metallic Black finish
Boost air for easy lighting
Integrated heat exchanger
Removable Cast Iron Trivet over Cooking Surface
Easy to use ash disposal system
Leveling Legs
Heavy plate-steel top
Inside and outside combustion air capable
Mobile Home Approved
East-West fuel loading
Specification
| dimensions |
|
| height |
1040mm |
| width |
737mm |
| depth |
622mm |
| Clearances |
|
| Rear clearance to combustible |
100mm |
| Side clearance to combustible |
300mm |
| Corner clearance to combustible |
50mm |
| Rear clearance to non combustible |
25mm |
| Side clearance to non combustible |
25mm |
| Corner clearance to non combustible |
25mm |
| Info |
|
| flue size |
150mm |
| min flue height |
4mtrs |
| hot water |
No |
| heating capacity |
300m2 |
| efficiency |
82% |
| Emissions |
1.0grms |
| wood length |
450mm |
| stove weight |
208kg |
WARRANTY
10 year warranty on fire Box, door glass, baffle LIFETIME warranty on any enamel finished 3 Year warranty on any electrical parts (including fan)
