Description

Technical Specs

Voltage 12V
Wattage 2W – 165W
Weight 63 LBS
Height 24 in.
Width 32 in.
Depth 16 in.
Surface Cooking Area 219 sq in.
Auger Motor RPM 4.7~5.2
Fan Motor RPM 0.45A; 4100 RPM
Grease Tray 13 Guage Steel
Igniter 12V; 100W
Height of Cooking Surface to Lid 7.75 in. clearance
Hopper Capacity (LBS of pellets) 9 LBS

Grill Functionality

A motor turns the auger which feeds pellets into the firebox. There, a hot rod automatically ignites the pellets, and a combustion fan below keeps them burning. Vents vertically line the inside of the Firebox creating the ultimate wood burning fire, circulating pure hardwood smoke flavour.
